OVERVIEW
The 810 PC Software Configuration Interface is designed for use with the DSE5xx, DSE5xxx, DSE4200 and DSE710/720 range of modules. It is intended to be used in conjunction with the DSE P810 For MS-Windows configuration software. The interface enables the user to access the configuration stored within the module to allow changes to be made to the various settings.
The interface kit comprises of:
* Interface module
* 25 way to 9 way RS232 adapter cable
* Interconnecting FCC 68- 8way cable which connects to the appropriate
* connector on the module. Software diskettes (or a CD) containing the P810 for Windows PC Software
* and various module) Configuration files to aid rapid module configuration.
Also included on the disk is a MS Word template, this can be used to make labels for the configurable LED on the module to identify their function. A slot is provided behind the clear window in the label for this, accessed by removing the front bezel.
The software will offer the user the following options:
* LOAD previous configurations from disk.
* SAVE new configurations to disk.
* READ the existing configuration from the module.
* WRITE a new configuration to the module.
* EDIT the configuration currently loaded in the PC.
* PRINT the configuration currently loaded in the PC.
* View the display from the module.
* SET- UP the software such as COM port selection.
* QUIT back to Ms-Windows
* Set- up the Optional Remote
* Telemetry & Control functions
