OVERVIEW
The DSE548 is an LED expansionmodule for the DSE52xx, DSE53xx and the DSEPower Series.
The module has been designed to display a maximumof eight local or remote (max 50metres)
individual LED indications.
The DSE548 is presented in a vertical enclosure. OPERATION
The LED are configured using the host module and the appropriate PC software interface.
The LED can be configured to be either:
Extinguish on command
Light on command
An additional LED indicates that a DC power supply is being received. There is also a flashing Link Lost LED fitted to indicate any communication problems with the host module.
When using two expansion modules together each module should be identified as either or. This is done by positioning the selector switch on the rear of each module.
