GP-J30-60T4i-SA 1-PHASE - John Deere | 30 kW 38 kVA

GP-J30-60T4i-SA 1-PHASE - John Deere | 30 kW 38 kVA

Worldwide Warranty
Quick Shipping
24/7 Support
SKU:
GP-J30-60T4i-1PHASE
Availability:
IN STOCK, Same day shipping Worldwide available
EPA Compliant:
EPA Tier i4 TPEM FLEX Mobile Prime
Power Ratings:
30KW 38KVA Standby / 27KW 34KVA Prime
Condition:
Brand New, 2 Year International Warranty
Quality:
100% designed and assembled in USA
Reliability:
Individually certified and load bank tested in USA

OVERVIEW

The John Deere 30KW, 38kVA 1 Phase Generator featuring a Tier 4 Interim compliant engine is designed for stationary emergency applications, and features top-quality components for reliable backup power when you need it most. A heavy duty diesel generator, Leroy Somer alternator and super-silent enclosure delivers enhanced performance and super-silent operation during unexpected power outages and blackouts.

30KW John Deere Diesel Generator Standard Features and Capabilities:

Engine

  • John Deere heavy duty electronic diesel engine
  • 4 stroke
  • 1,800 RPM
  • Turbocharged
  • U.S. EPA Tier 4i compliant engine for Stationary Emergency applications

Alternator

  • Designed and manufactured by Leroy Somer, a leading manufacturer of industrial alternators
  • Features a Leroy Somer R120 Automatic Voltage Regulator
  • Single bearing
  • 3 phase
  • 4 pole
  • IP23 protection
  • Insulation class C

Enclosure

  • Longer component lifespan and enhanced operator safety achieved through a 29dB(A) internal-mounted critical silencer and flexible exhaust connector
  • Scratch- and corrosion-resistant automotive-grade textured finished with enhanced edge coverage
  • Up to 51mm acoustic insulation with hydrocarbon sealing film meets FMVSS 302 flammability classification
  • Easier access to the set controller, breaker and service points through multi-personnel doors
  • Interchangeable panel construction allows for easy replacement and service access without compromising enclosure design
  • Weather-protective design features a vertical air discharge outlet grille to redirect cooling air up and above the enclosure
  • Meets and exceeds:
    • NFX41002 Salt spray test
    • NFT30049 UV Performance test
    • NFT30038 Paint adhesion test
    • 2000/14EC Low sound directives

Fuel Tank and Features

  • Incorporated metallic fuel tank for day use
  • Electronic fuel level sender for easy monitoring

Control Panel and Features

  • Digital Deep Sea DSE 7320 controller comes standard (Optional upgrade to Deep Sea DSE 8610 for paralleling)
  • Digital auto-start/stop control panel for enhanced control over generator operation
  • CE and UL compliant for enhanced safety

Additional Features and Capabilities of the 30KW John Deere Diesel Generator Include:

  • Main line circuit breaker with a maximum output rated for complete protection
  • Seamless interoperation with ATS/AMF through auto-start control feature
  • 12V charged DC starting battery with electrolyte and cables deliver quick and reliable startup
  • Standard installation of a dry type air filter, fuel filter and oil filter elements allow easier maintenance and longer component lifespan
  • Super-quiet operation achieved with mechanically-welded chassis and vibration isolators
  • Accepts 100% rated load in one step as per NFPA110
  • Meets ISO8528-5 class G-3 for transient response
  • Compliant with:
    • ISO3046
    • ISO8528
    • BS4999
    • BS5514
    • BS5000PT99
    • AS1359
    • IEC34
    • UTE5100
    • VDE0530
    • ISO9001:2000

Compatible Accessories and Options for the 30KW John Deere Diesel Generator:

The 30KW John Deere diesel generator is compatible with a wide range of accessories. Custom-configure your generator with accessories including:

  • Weatherproof and sound attenuated enclosures made with steel or aluminum
  • UL142 listed double wall fuel tanks from 50 to 10,000 gallons
  • UL1008 listed automatic transfer switches from 50 to 3,000 AMP
  • D.O.T. compliant heavy duty road trailers from 3000 to 30,000 pounds
  • Automatic battery chargers, engine preheaters, remote annunciators and many more easy-to-install accessories for enhanced generator performance
