In the event of an unexpected power outage, the John Deere 250 KW 313 kVA Generator is ready to provide your business with continuous and reliable power. It is fully packaged with a heavy duty, 4 stroke, 1800 rpm, electronic engine. This turbocharged generator complies with the highest industry standards, including U.S. EPA Tier 3 certification for stationary emergency applications.
250 KW John Deere Diesel Generator Standard Features and Capabilities:
|
Engine
|
- John Deere 6090HFG86-2463 engine
- 1800 rpm
- 4 stroke
- Turbocharged and aftercooled (air-to-air)
- U.S. EPA Tier 3 compliant engine for stationary emergency application
|
|
Alternator
|
- Samford Cummins alternator
- 3 phase
- 4 pole
- Direct/single bearing
- IP23 protection
- Insulation class H
- Main line circuit breaker, maximum output rated for complete protection
- 12V charging alternator and 12V DC electric starter motor
- 12V charged DC starting battery with electrolyte and cables
|
|
Enclosure
|
- Vibration isolators are included in its mechanically welded chassis
- 12 gauge electro-zinc powder coated steel for maximum corrosion resistance (phosphatizing degreasing, non-chromic passivation, osmosis purified rinsing and high-durability polyester resin thermosetting powder paint)
- 29dB(A) internal-mounted critical silencer and flexible exhaust connector offering maximum component life and operator safety
- Resistant to fading, scratches and corrosion
- Automotive-grade textured finish resulting in advanced corrosion and abrasion protection as well as enhanced edge coverage and color retention
- Meets FMVSS 302 flammability classification and repels moisture absorption with acoustic insulation with hydrocarbon sealing film up to 51mm (2 in)
- Interchangeable modular panel construction allows complete serviceability or replacement without compromising enclosure design
- Multi-personnel doors for easy access to generator set controller, breaker and service points
- Externally mounted emergency stop button, single point lifting hook and tamper-proof “securit” viewing control window
- Cooling air discharge, weather protective design featuring a vertical air discharge outlet grille
- Redirects cooling air up and above enclosure to reduce ambient noise
- Cooling/combustion air intake with a horizontal air inlet, sized for maximum cooling airflow
- Lifetime longevity with heavy duty polyamide plastic hinges, dichromate galvanized bolting and stainless-steel rivets
- Meets and exceeds:
- NFX41002 Salt spray test
- NFT30049 UV Performance test
- NFT30038 Paint adhesion test
- 2000/14EC Low sound directives
|
| Fuel Tank and Features |
- 132 gallon integral tank
- 9 hours @ 75% prime load
- 8 hours @ 100% prime load
- Incorporated metallic fuel tank for day use
- Electronic fuel level sender
|
|
Control Panel and Features
|
- Deepsea DSE7320 Controller
- Digital auto-start/stop control panel
- 132x64 LCD display
- Fully configurable via a free downloadable PC software
- 250 events log including date and time make fault finding effortless
- Remote monitoring and control via Ethernet/RS485 and SMS messaging via GSM/SIM card options available
- Coolant temperature alarm/shutdown
- Oil pressure and low pressure alarm/shutdown
- Display features oil temp, hours, battery charge, frequency, KW, kVA and PF
- Voltage under/over protection
- Amp over current protection
- Compliant with CE and UL
|
Additional Features and Capabilities of the 250 KW John Deere Diesel Generator Include:
- Interoperational with ATS/AMFAuto start control feature included
- Dry type air filter, fuel filter and oil filter elements installed
- Each unit prototype and individually factory load bank tested
- The generator accepts 100% rated load in one step as per NFPA110 and meets ISO8528-5 class G-3 for transient response
- Compliant with:
- ISO3046
- ISO8528
- BS4999
- BS5514
- BS5000PT99
- AS1359
- IEC34
- UTE5100
- VDE0530
- ISO9001:2000
Compatible Accessories and Options for the 250 KW John Deere Diesel Generator Include:
Configure your generator set for your unique power needs with compatible accessories, including:
- Steel or aluminum weatherproof, sound attenuated enclosures
- Double wall fuel tanks from 50 to 10,000 gallons are UL142 listed
- UL1008 listed, automatic transfer switches from 50 to 3000 Amp
- D.O.T. compliant heavy duty road trailers from 3,000 to 30,000 lbs.
- Automatic battery chargers, engine preheaters, remote annunciators also available
