OVERVIEW
Deep Sea DSE9130 Battery Charger
Deep Sea Electronics is one of the leading brands of controllers and power supplies worldwide. Based in the United Kingdom, this leading manufacturer produces a wide variety of intelligent battery chargers providing exceptional performance and efficiency in a compact form to 150 countries. Deep Sea Power products range from 12, 24, and 48 volts, making them suitable for a wide variety of applications.
DEEPSEA 9130-00 Generator Battery Charger
The DSE9130 is a 12 volt, 5 amp battery charger designed to be permanently connected to a battery, keeping it charged to its maximum capacity at all times. It may be mounted via DIN rail as well as directly onto the chassis. This charger not only includes an LED indicator for the purpose of signaling when the charger is in a normal or overload condition, but is also designed to continue operating during cranking and running of the Generator Set and accepts multiple AC voltage connections.
This DeepSea battery charger provides flexibility for operation with various battery type technologies, prevents damage to the charger and battery to provide dependable operation, operates at Power Save Mode, has no moving parts, allows chargers to be linked together to increase the current output available and provides a quicker charging cycle for discharged batteries.
SPECIFICATIONS:
- Voltage Range (L-N): 90V to 250V
- DC Output: 5 Amp 12 Volt
- Ripple/Noise: <1%
- Efficiency: >80%
- Regulation:
- Line: <0.001% Vo
- Load: 1% Vo
- Protections:
- Short Circuit
- Over Voltage
- Over Current
- Reverse Polarity
PRINCIPAL FEATURES AND BENEFITS:
- Provides constant current and voltage
- Prevents battery damage due to overcharge
- Provides auto recovery on fault condition removal
- Assistance with improvement of battery life and operating performance
- Provides remote signal in the event of a power failure
- Guarantees a low output ripple
DIMENSIONS:
- 5.4" x 5.5" x 2.5"
- WEIGHT: ~2 lbs.
