OVERVIEW
Deep Sea DSE9702 Battery Charger
Deep Sea Electronics, one of the world’s leading brands in controllers and power supplies, is based in the United Kingdom and distributes their products to over 150 countries around the globe. DSE’s products emphasize performance, efficiency and high quality above all else.
DEEPSEA 9702-01 Generator Battery Charger
The DSE9702-01 5 amp, 12 volt battery charger can either be DIN rail mounted or screw mounted. This switch-mode module is specially designed to maximize the lifespan of the batteries that it charges. The connection that this charger makes with batteries is permanent, and it is capable of functioning both while running and cranking. The charger's LED display indicates its conditions at all time, whether in normal condition or overload condition.
SPECIFICATIONS:
- Voltage Range (L-N): 90V to 305V
- DC Output: 5 Amp 12 Volt
- Frequency Range: 48 Hz to 65 Hz
- Ripple/Noise: <1%
- Efficiency: >80%
- Regulation:
- Line: <0.001% Vo
- Load: 1% Vo
- Protections:
- Short Circuit
- DC Over Voltage
- DC Over Current
- Reverse Polarity
- Operating Temperature Range: -30 °C to +55 °C
- Storage Temperature Range: -40 °C to +85 °C
PRINCIPAL FEATURES AND BENEFITS:
- Protections against short circuiting, over voltage, over current, and reverse polarity
- Flexibly suits a wide range of different battery types with equal efficiency
- Charge fail output
- Switched mode design
- Battery performance-equalizing Boost Mode
- Energy-conserving Power Save Mode
DIMENSIONS:
- DIN Rail Mounted:
- 1.88" x 5.23" x 4.33"
- Chassis Mounted:
- 1.88" x 6.02" x 4.40"
- WEIGHT: 0.88lb
