OVERVIEW
Deep Sea DSE9701 Battery Charger
With the promise of high quality and continual progress, Deep Sea Electronics has established itself as one of the world’s leading power supply brands over the past 40 years. Deep Sea Power product line consist of a wide variety of generator controls and battery charger equipment ranging from 12 to 48 volts.
DEEPSEA 9701-01 Generator Battery Charger
The DSE9701-01 5 amp, 24 volt battery charger remains permanently affixed to the batteries the users charge with it, mountable with either a chassis or a DIN rail. This is a switch-mode module with a convenient LED display that indicates whether the charger is in its default or overload condition. With its highly accommodating compatibility with a wide range of battery types and helpful protections, this battery charger is a satisfying combination of versatility, reliability, and convenience.
SPECIFICATIONS:
- Voltage Range (L-N): 90V to 305V
- DC Output: 5 Amp 24 Volt
- Frequency Range: 48 Hz to 65 Hz
- Ripple/Noise: <1%
- Efficiency: >80%
- Regulation:
- Line: <0.001% Vo
- Load: 1% Vo
- Protections:
- Short Circuit
- DC Over Voltage
- DC Over Current
- Reverse Polarity
- Operating Temperature Range: -30 °C to +55 °C
- Storage Temperature Range: -40 °C to +85 °C
PRINCIPAL FEATURES AND BENEFITS:
- Designed to constantly maintain both its current and voltage with steady consistency
- Automatic float mode return
- Automatic recovery when removing fault conditions
- Protections account for short-circuiting, current limiting, reverse polarity and overcharging
- Configurable either to start sets only when the load demands them or to start all loads by default
- Can operate both while cranking and running
DIMENSIONS:
- DIN Rail Mounted:
- 1.88" x 5.23" x 4.33"
- Chassis Mounted:
- 1.88" x 6.02" x 4.40"
- WEIGHT: 0.88lb
