OVERVIEW
Deep Sea DSE9484 Battery Charger
Over the past 40 years, Deep Sea Electronics has achieved great success as a major manufacturer and distributor, shipping to about 150 different countries around the world. With a reputation for high standards and attention to detail, DSE is constantly enhancing charging technology worldwide.
DEEPSEA 9484-01 Generator Battery Charger
The DSE9484-01 15 amp, 12 volt battery charger is made to operate both while in the process of cranking and running. This module is configured for high levels of safety, reliability, versatility and efficiency. The design is flexible enough to easily accommodate a wide range of different battery types, and no matter what type is being charged, the battery life is optimized for maximum longevity.
SPECIFICATIONS:
- Voltage Range (L-N): 90V to 305V
- DC Output: 15 Amp 12 Volt
- Frequency Range: 48 Hz to 64 Hz
- Ripple/Noise: 1%
- Efficiency: >90%
- Regulation:
- Line: <0.5% Vo
- Load: 1% Vo
- Charge Failure Relay: 3 amps at 30 volts/li>
- Protections:
- Short Circuit
- DC Over Voltage
- DC Over Current
- Reverse Polarity
- Over Temperature
- AC Under & Over Voltage
- Operating Temperature Range: -30 °C to +55 °C
- Storage Temperature Range: -30 °C to +70 °C
PRINCIPAL FEATURES AND BENEFITS:
- Designed with a host of protections to secure its defense against various over and under-voltage risks
- LED displays immediately notify the user of its charging status
- Digital microprocessor technology for more safety and efficiency
- Charge levels are freely customizable
- Charging curves can be adjustable
- Compatible with an extensive curve library of battery types
DIMENSIONS:
- 9.44" x 10.35" x 3.50"
- WEIGHT: 5.51lb
