OVERVIEW
Deep Sea DSE9481 Battery Charger
Established in 1975 in the United Kingdom, Deep Sea Electronics aims to offer more intelligent battery and power solutions to companies across the world. With products ranging at 12, 24 and 48 volts, DSE batteries and chargers are suitable for a wide range of applications.
DEEPSEA 9481-01 Generator Battery Charger
The DSE9481-01 5 amp, 12 volt battery charger can conveniently operate both while running and cranking. Users with more than one AC voltage connection to use at once will be pleased with the fact that this charger can accept several voltage connections at once without a drop in efficiency. Any problematic fault conditions that arise can be instantly viewed with the three LEDs built into the battery charger. In addition to fault conditions, the LEDs also display the charging status.
SPECIFICATIONS:
- Voltage Range (L-N): 90V to 305V
- DC Output: 5 Amp 12 Volt
- Frequency Range: 48 Hz to 64 Hz
- Ripple/Noise: <1%
- Efficiency: >86%
- Regulation:
- Line: <0.5% Vo
- Load: 2% Vo
- Charge Failure Relay: 3 amps at 30 volts/li>
- Protections:
- Short Circuit
- DC Over Voltage
- DC Over Current
- Reverse Polarity
- Over Temperature
- AC Under & Over Voltage
- Operating Temperature Range: -30 °C to +55 °C
- Storage Temperature Range: -30 °C to +70 °C
PRINCIPAL FEATURES AND BENEFITS:
- Charging profiles of both three and four stages
- Current limit can be custom-configured to meet the exact desired specifications of the user
- Automatic battery detection
- Automatic self-testing
- Auto recovery for output short circuiting and inversion polarity
- Compatible with a wide range of different battery models
DIMENSIONS:
- 2.75" x 7.87" x 5.11"
- WEIGHT: 1.65lb
