OVERVIEW
Deep Sea DSE9480 Battery Charger
Since 1975, the UK’s Deep Sea Electronics has been meeting the power needs of companies all over the globe. As one of the world’s top manufacturers of controllers and power suppliers, DSE’s products are suitable for a wide variety of applications.
DEEPSEA 9480-01 Generator Battery Charger
The DSE9480-01 MKII intelligent 10 amp, 12 volt battery charger can be is specially designed high flexibility, cost effectiveness, and battery life longevity. The technological implementations facilitate superior safety, reliability and accuracy. The charger is compatible with a satisfyingly accommodating range of battery chargers, and with digital microprocessor technology, the safety of the model is well optimized. After being activated with any one of a diverse range of installation options, the charger is capable of operating in both manual and automatic boosting modes.
SPECIFICATIONS:
- Voltage Range (L-N): 90V to 305V
- DC Output: 10 Amp 12 Volt
- Frequency Range: 48 Hz to 64 Hz
- Ripple/Noise: <1%
- Efficiency: >86%
- Regulation:
- Line: <0.5% Vo
- Load: 2% Vo
- Charge Failure Relay: 3 amps at 30 volts/li>
- Protections:
- Short Circuit
- DC Over Voltage
- DC Over Current
- Reverse Polarity
- Over Temperature
- AC Under & Over Voltage
- Operating Temperature Range: -30 °C to +55 °C
- Storage Temperature Range: -30 °C to +70 °C
PRINCIPAL FEATURES AND BENEFITS:
- Designed with both an Automatic Boost mode greatly improving the performance of the battery through equalization and enhancement
- Power Save mode to prevent the charger from wasting energy at full capacity
- Can be conveniently integrated into external system configurations with MODBUS RTU and an RS485 cable
- Remains permanently attached to its AC supply and battery with no need for any tedious, risky disconnection
- High flexibility for maximum battery life
- Automatic power de-rating for high temperature operation
DIMENSIONS:
- 2.75" x 7.87" x 5.11"
- WEIGHT: 1.65lb
