OVERVIEW
Deep Sea DSE9474 Battery Charger
In 1975, Deep Sea Electronics was established in the United Kingdom. Formed with the objective to offer more intelligent battery and power solutions, four decades later the company stands proudly, shipping its varied products to over 150 countries worldwide.
DEEPSEA 9474-01 Generator Battery Charger
The DSE474-01 intelligent 30 amp, 24 volt battery charger is fully configurable with DSE Configuration Suite PC software. The chargers feature three built-in LEDS that allow the fault conditions and the charging status to be easily monitored at all times. The battery charger can operate both in its cranking mode and its running mode. The charging curves can be modified to meet the preferences of the user, maximizing the batteries' longevity.
SPECIFICATIONS:
- Voltage Range (L-N): 90V to 305V
- DC Output: 30 Amp 24 Volt
- Frequency Range: 48 Hz to 64 Hz
- Ripple/Noise: 1%
- Efficiency: >90%
- Regulation:
- Line: <0.5% Vo
- Load: 1% Vo
- Charge Failure Relay: 3 amps at 30 volts/li>
- Protections:
- Short Circuit
- DC Over Voltage
- DC Over Current
- Reverse Polarity
- Over Temperature
- AC Under & Over Voltage
- Operating Temperature Range: -30 °C to +55 °C
- Storage Temperature Range: -30 °C to +70 °C
PRINCIPAL FEATURES AND BENEFITS:
- Protections against short circuiting, over voltage, under voltage, DC over current, reverse polarity, and overheating
- PT1000 temperature sensor for battery temperature regulation
- CAN interface
- Three and four-stage charging profiles
- Both manual and automatic boost modes
- Digital Microprocessor Technology optimizes the charger's safety
DIMENSIONS:
- 9.44" x 10.35" x 3.50"
- WEIGHT: 5.51lb
