OVERVIEW
Deep Sea DSE9472 Battery Charger
In the power supplies industry, Deep Sea Electronics has almost become a byword for choice and quality. With over 40 years’ experience, DSE is one of the most reliable manufacturers of intelligent, high powered battery chargers around.
DEEPSEA 9472-01 Generator Battery Charger
The DSE9472-01 5 amp, 24 volt battery charger's charging status and fault conditions can be conveniently monitored with three LEDS. Whether cranking or running, the charge can operate with consistent effectiveness. Mountable with either a DIN or rail or chassis, the charger can be linked with several voltage connections at once. This particular model is a switch-mode design, and if the user wishes, its default charging curves and can adjust to meet their specific preferences.
SPECIFICATIONS:
- Voltage Range (L-N): 90V to 305V
- DC Output: 5 Amp 24 Volt
- Frequency Range: 48 Hz to 64 Hz
- Ripple/Noise: <1%
- Efficiency: >86%
- Regulation:
- Line: <0.5% Vo
- Load: 2% Vo
- Charge Failure Relay: 3 amps at 30 volts/li>
- Protections:
- Short Circuit
- DC Over Voltage
- DC Over Current
- Reverse Polarity
- Over Temperature
- AC Under & Over Voltage
- Battery Charger Failure
- Operating Temperature Range: -30 °C to +55 °C
- Storage Temperature Range: -30 °C to +70 °C
PRINCIPAL FEATURES AND BENEFITS:
- Flexible design allows it to easily connect to a wide variety of different battery types with equal effectiveness
- Upon full charge capacity, the charger enters Power Save Mode to conserve energy expenditure
- Can be configured with DSE Configuration Suite PC Software
- Can be integrated into external systems via RS5485 and MODBUS RTU
- Can be linked with multiple additional chargers to maximize current output
- Automatic self-testing capability
DIMENSIONS:
- 2.75" x 7.87" x 5.11"
- WEIGHT: 1.65lb
