OVERVIEW
Deep Sea DSE9470 Battery Charger
Deep Sea Electronics is a proud UK manufacturer, but with a client base spread throughout 150 countries and staff employed in four continents, it is also considered a global giant. Offering a range of over 140 power products, DSE is able to meet almost any requirement.
DEEPSEA 9470-01 Generator Battery Charger
The DSE9470-01 MKII 10 amp, 24 volt battery charger can be modified to run with the user's desired custom charging curve levels. This charger operates with DSE Configuration Rate Software and can either be chassis-mounted or DIN rail mounted. With the right charging curve configuration, the lifespan of the charger's batteries can be extended to their maximum longevity. The charger can run equally efficiently either while in its cranking mode or its running mode. LEDs implemented into the charger allow the user to monitor both charging status and any fault conditions that arise.
SPECIFICATIONS:
- Voltage Range (L-N): 90V to 305V
- DC Output: 10 Amp 24 Volt
- Frequency Range: 48 Hz to 64 Hz
- Ripple/Noise: <1%
- Efficiency: >86%
- Regulation:
- Line: <0.5% Vo
- Load: 2% Vo
- Charge Failure Relay: 3 amps at 30 volts/li>
- Protections:
- Short Circuit
- DC Over Voltage
- DC Over Current
- Reverse Polarity
- Over Temperature
- AC Under & Over Voltage
- Battery Charger Failure
- Operating Temperature Range: -30 °C to +55 °C
- Storage Temperature Range: -30 °C to +70 °C
PRINCIPAL FEATURES AND BENEFITS:
- A host of protections for its inputs and outputs to ensure a superior degree of safety
- Automatic battery detection
- Self-testing functionality
- Automatic power de-rating as a precautionary measure for operation in warmer temperatures
- Requires no external intervention to activate its boost mode
- Can simultaneously serve as both a battery charger and power supply
DIMENSIONS:
2.75" x 7.87" x 5.11"
WEIGHT: 1.65lb
