OVERVIEW
Deep Sea DSE9461 Battery Charger
Deep Sea Electronics is one of the world’s primary manufacturers of battery charger equipment and generator controls ranging in 12, 24 and 48 volts. Employing over 120 people and selling their products to over 150 countries, their products are surely setting new standards in charging technology.
DEEPSEA 9461-11 Generator Battery Charger
The DSE9461-11 battery charger operates at 12 volts and 10 amps. The battery charger is designed with a convenient LCD display to monitor the battery's charging status and an all-inclusive range of protections to optimize its safety. This battery charger stays consistently cool during operation, protecting it from the risk of overheating when operating in significantly warmer climates. The battery charger's highly adaptable battery configuration can be paired with a wide variety of different installations and user-specified parameters.
SPECIFICATIONS:
- Voltage Range (L-N): 90V to 305V
- DC Output: 10 Amp 24 Volt
- Frequency Range: 48 Hz to 64 Hz
- Ripple/Noise: <1%
- Efficiency: >86%
- Regulation:
- Line: <0.5% Vo
- Load: 2% Vo
- Auxiliary Input: 100 mA DC at 12 volts
- Protections:
- Short Circuit
- DC Over Voltage
- DC Over Current
- Reverse Polarity
- Over Temperature
- AC Under & Over Voltage
- Battery Charger Failure
- Operating Temperature Range: -30 °C to +55 °C
- Storage Temperature Range: -40 °C to +85 °C
PRINCIPAL FEATURES AND BENEFITS:
- Remote display to conveniently monitor the battery's charging status from remote locations
- Conservative yet efficient operation preserves a generous amount of battery life and optimizes the overall performance
- The battery's temperature is directly measured, ensuring that the charger's performance is constantly matched to the most fitting level indicated by its battery's manufacturer
- Users have the option of enacting battery temperature compensation with the included PT1000 temperature sensor
- Fully adjustable current limit
- Designed for permanent connection to the battery, removing the need for removal during high load levels
- LCD Display
DIMENSIONS:
- 6.49" x 12" x 4.33"
- WEIGHT: 5.06lb
