OVERVIEW
Deep Sea DSE9460 Battery Charger
The UK’s Deep Sea Electronics is virtually unmatched when it comes to proficiency in controllers and power supplies. Offering over 140 products which provide solutions to a large variety of applications, DSE has been at the top of their game for over 40 years now.
DEEPSEA 9460-12 Generator Battery Charger
The DSE9460-12 5 amp, 24 volt battery charger model is designed with both an LCD display and an analogue meter. Like other chargers in its class, this model has been designed for efficient operation with high levels of safety and durability. While the default charging curves are optimal, they can be adjusted via PC software if the owner desires a slightly more fine-tuned configuration. Because of this enclosed battery charger's intelligent design, it operates without expending an unnecessary amount of energy, sparing the overall battery life.
SPECIFICATIONS:
- Voltage Range (L-N): 90V to 305V
- DC Output: 5 Amp 24 Volt
- Frequency Range: 48 Hz to 64 Hz
- Ripple/Noise: <1%
- Efficiency: >86%
- Regulation:
- Line: <0.5% Vo
- Load: 2% Vo
- Auxiliary Input: 100 mA DC at 12 volts
- Protections:
- Short Circuit
- DC Over Voltage
- DC Over Current
- Reverse Polarity
- Over Temperature
- AC Under & Over Voltage
- Battery Charger Failure
- Operating Temperature Range: -30 °C to +55 °C
- Storage Temperature Range: -40 °C to +85 °C
PRINCIPAL FEATURES AND BENEFITS:
- Charging profiles of two, three and four stages
- Current limit can be adjusted to the owner's liking
- The battery's condition can be maintained with either Manual or Automatic boost storage charge functionality
- Can be used as power supply, a battery charger, or it can even fulfill both roles simultaneously
- All-inclusive range of protections for any issues with either under or over voltage in the battery charger's AC input and output
- LCD Display and Analog Meters
DIMENSIONS:
- 6.49" x 12" x 4.33"
- WEIGHT: 5.06lb
