OVERVIEW
Deep Sea DSE9460-11 Battery Charger
Deep Sea Electronics of the United Kingdom has surpassed expectations when it comes to excellence in controllers and power supplies. With over 140 different products providing flexible solutions for various applications, DSE is one of the most versatile manufacturers currently on the market.
DEEPSEA 9460-11 Generator Battery Charger
The DSE9460-11 5 amp, 24 volt battery charger variation has an LCD display and is designed for 24-volt operation. This is a charger that features an accommodating range of protections, adjustable parameters, and integration potential. This charger, enclosed in high-grade metal, is a highly practical junction between durability, usability, safety and longevity in one sleek package. The charger can be used as soon as it's removed from its box, though if preferred, it can also be connected to a PC with a USB cable for either pre-set or custom-configured curve modification.
SPECIFICATIONS:
- Voltage Range (L-N): 90V to 305V
- DC Output: 5 Amp 24 Volt
- Frequency Range: 48 Hz to 64 Hz
- Ripple/Noise: <1%
- Efficiency: >86%
- Regulation:
- Line: <0.5% Vo
- Load: 2% Vo
- Auxiliary Input: 100 mA DC at 12 volts
- Protections:
- Short Circuit
- DC Over Voltage
- DC Over Current
- Reverse Polarity
- Over Temperature
- AC Under & Over Voltage
- Battery Charger Failure
- Operating Temperature Range: -30 °C to +55 °C
- Storage Temperature Range: -40 °C to +85 °C
PRINCIPAL FEATURES AND BENEFITS:
- Battery charger can remain consistently cool while it runs without expending too much energy
- With an RS485 cable, the system can be integrated with MODBUS RTU for remotely monitoring its status and battery charging condition
- Several chargers can be linked together at once to increase the size of the current output
- Charger can also be permanently attached to its battery with no need for any disconnection during high load phases
- Full set of highly beneficial protections
- Optional External remote LCD
- LCD Display
DIMENSIONS:
- 6.49" x 12" x 4.33"
- WEIGHT: 5.06lb
