OVERVIEW
Deep Sea DSE9460 Battery Charger
Thriving for over 40 years in the industry, the UK’s Deep Sea Electronics is one of the world’s leading manufacturers of battery charger equipment, delivering products to over 150 countries worldwide.
DEEPSEA 9460-01 Generator Battery Charger
The DSE9460-01 5 amp, 12 volt battery charger is a securely enclosed model, specially designed for optimal energy conservation, efficiency and ease of use. While the charger's curve levels can be adjusted via PC with a USB cable connection, the charger can also be used independently right after taking it out of the box. When adjusting the curve levels with a PC, the user can either choose from preset parameters or precisely modify the curves to their exact specifications.
SPECIFICATIONS:
- Voltage Range (L-N): 90V to 305V
- DC Output: 5 Amp 12 Volt
- Frequency Range: 48 Hz to 64 Hz
- Ripple/Noise: <1%
- Efficiency: >86%
- Regulation:
- Line: <0.5% Vo
- Load: 2% Vo
- Auxiliary Input: 100 mA DC at 12 volts
- Protections:
- Short Circuit
- DC Over Voltage
- DC Over Current
- Reverse Polarity
- Over Temperature
- AC Under & Over Voltage
- Battery Charger Failure
- Operating Temperature Range: -30 °C to +55 °C
- Storage Temperature Range: -40 °C to +85 °C
PRINCIPAL FEATURES AND BENEFITS:
- Front control panel makes it easy to visually examine the status of batteries at all times
- The type of display can be adjusted to the owner's preference
- Charge output can be exponentially increased by linking modules together with paralleling feature
- Charger's output current can be precisely adjusted for an optimal fit with the size of whatever battery it's charging
- Maximizes battery length with flexibility
- Boost mode requires no external intervention
- LCD Display
DIMENSIONS:
- 6.49" x 12" x 4.33"
- WEIGHT: 5.06lb
