* This part is no longer manufactured. It has been replaced by the Leroy Somer R250.

SAME EXACT AVR AS:

• Leroy Somer Voltage Regulator AEM110RE014 AVR
• SDMO Voltage Regulator 330410345 AVR
• FG Wilson Voltage Regulator 922-197 AVR
• Olympian Voltage Regulator 922-197 AVR

Characteristics:

• Voltage regulation: around ± 0.5%.

• Voltage supply/sensing range 85 to 139 V (50/60 Hz)

• Rapid response time (500 ms) for a transient voltage variation amplitude of ± 20% - Voltage setting P1

• Stability setting P2.

• Power supply protected by 8 A fuse, slow- blow action (tolerates 10 A for 10 s)

• Frequency: 50 Hz with ST3 jumper

• 60 Hz without ST3 jumper

• Factory-set underspeed protection P3. 2.2

• R230 AVR option

• Potentiometer for remote voltage adjustment, 1000 © / 0.5 W min: adjustment range ± 5%. - Remove the ST4 jumper.
